Technical Specifications

• IR day and night vision for recording
• Recording resolution:1280*720/848*480/ 640x480 pixels
• Video format:H.264
• Repeat storage by section: 2/5/15 minutes or off
• Power source: Built-in rechargeable battery or 12V/24V Car Charger
• Supports SD/MMC card ( From 1GB up to 32GB)
• Microphone: can record sound
• Interface: HDMI & USB2.0

Setting the functions:
Turn on the DVR and  press to enter into setting interface.Menu Button. Confirm by and select  by for the following setting. Press again to exit after finished.

1.Movie Size: Select  [1280x720/848x480 /640x480pixels]
2 Audio Recording: Select On or Off
3 Volume: From 0 to7
4 Motion Detect: Select  On or Off
5 FPS: Select 10FPS/20FPS/30FPS
6 Recording time: select  [2/5/15]minute to decide how many time will be storage per one section  or Off.
7 Date Stamp: Select  [Date & Time Stamp]or [No Stamp]
8 Date/Time: Set correct  recording Date and time.
9 Language: Select  [English/Chinese/Russian]
10 LightFrequency: set  [50/60Hz].
11 Restore Default:.  Select[ Yes]or [No].
12 Version: Show  the software version number.

Preview on the HD TV
Connect the HDMI link  of DVR with the HD TV, then turn on the DVR And enter into the preview  mode automatically,and the operating steps are same as previewon the  screen.

Note:
1) Please insert  the SD/ MMC card before recording.
2) Please adjust the  time display before recording. If not set a time, the DVR cannotrecord.
3) This DVR records in  cycle if you choose 2/5/15 minutes as storage time.When the storage  medium is full, it will record from the beginning again and erase over  the previously recorded material automatically.It will have 3 seconds  paus time,and namely the contents in the 3 seconds will not recorded.If  select Off,when the storage medium is full,it shows Card Full and stop  recording.
4) Because the DVR is  DC5V input,please use the attached car charger. It have adaptor 12V/24V  transfers to 5V already.
5) Whenyou cannot stop  recording by pressing REC button, please check if you have selected the  is.Montion Detect ON. If yes,please select.OFF

What is including:

1. 1 x Camcorder
2. 1 x Manual Li-ion battery
3. 1 x Mount
4. 1 x USBCable
5. 1 x Car Charger (Include the adpator 12V/24V transfers to 5V)

Description in Russian
12 PCS IR
§®§Ñ§ä§â§Ú§è§Ñ  1/3 CMOS
§©§Ñ§á§Ú§ã§î §Ó§Ú§Õ§Ö§à AVI 1280§ç720 §ä§à§é§Ö§Ü, 848§ç480 §ä§à§é§Ö§Ü, 640x480 §ä§à§é§Ö§Ü
§±§Ú§ä§Ñ§ß§Ú§Ö §â§Ö§Ô§Ú§ã§ä§â§Ñ§ä§à§â§Ñ  12-24 §£
§¢§Ñ§ä§Ñ§â§Ö§ñ §â§Ö§Ô§Ú§ã§ä§â§Ñ§ä§à§â§Ñ  §¡§Ü§Ü§å§Þ§å§Ý§ñ§ä§à§â Li-ion
§¥§Ú§ã§á§Ý§Ö§Û  2.4 TFT §¸§Ó§Ö§ä§ß§à§Û
§®§Ú§Ü§â§à§æ§à§ß  §Ó§ã§ä§â§à§Ö§ß§ß§í§Û
§µ§Ô§à§Ý §à§Ò§Ù§à§â§Ñ §Ü§Ñ§Þ§Ö§â§í  140 §Ô§â§Ñ§Õ§å§ã§à§Ó
§±§Ñ§Þ§ñ§ä§î  SD §Ú§Ý§Ú MMC §à§Ò§ì§Ö§Þ§à§Þ §à§ä 256 §®§Ò §Õ§à 32 §¤§Ò
